Circular Polarity RFID Panel Antenna
S9028PCLF S9028PCRF
The Laird PAL86518H-FNF/PAR86518H-FNF antennas are circularly polarized panel antennas that
provide reception and transmission of signals in the 865-956 MHz frequency band. Laird’s industry
renowned design methodology achieves maximum efficiency and performance across the entire
frequency band.
provide reception and transmission of signals in the 865-956 MHz frequency band. Laird’s industry
renowned design methodology achieves maximum efficiency and performance across the entire
frequency band.
865-956 MHZ 8.5 dBic CIRCULAR POLARITY PANEL
The Laird PAL86518H-FNF/PAR86518H-FNF antennas are circularly polarized panel antennas that provide reception and transmission of signals in the 865-956 MHz frequency band. Laird’s industry renowned design methodology achieves maximum efficiency and performance across the entire frequency band.
Both VSWR and axial ratios are excellent and allow the user to achieve the maximum performance for an antenna of this type. The antenna is housed in a heavy duty radome enclosure that can be directly wall mounted. An optional articulating mount allows either wall or mast mounting.
The antenna is offered with a Fix N connector.
| FEATURES | APPLICATIONS |
|---|---|
| Low profile | Warehouse |
| Extremely low VSWR and axial ratio | Distribution center |
| Wide band | Airports and hospitals |
| Weather and UV resistant radome | Transit terminals |
| Wide range of connector and cable options | Conveyer belt |
| Left hand and right hand CP versions | |
| IP 67 |
