Circular Polarity RFID Panel Antenna
S9028PCLF S9028PCRF
The Laird Technologies’ S8655P is the latest addition to the high-performance RFID antenna
lineup and is the only UHF RFID antenna available to the market that offers no-compromise
performance in a small package. At only 5.2” square the antenna offers a gain specification of
5.0 dBic and axial ratio better than 2 dB. In effect the antenna is providing the performance one
would expect of a much larger antenna. The antenna is not only mechanically robust but is less
likely to be exposed to excessive damage by virtue of its reduced size.
lineup and is the only UHF RFID antenna available to the market that offers no-compromise
performance in a small package. At only 5.2” square the antenna offers a gain specification of
5.0 dBic and axial ratio better than 2 dB. In effect the antenna is providing the performance one
would expect of a much larger antenna. The antenna is not only mechanically robust but is less
likely to be exposed to excessive damage by virtue of its reduced size.
865-870 MHz 5.5 dBic CP MINI RFID PANEL ANTENNA
The Laird Technologies’ S8655P is the latest addition to the high-performance RFID antenna lineup and is the only UHF RFID antenna available to the market that offers no-compromise performance in a small package. At only 5.2” square the antenna offers a gain specification of 5.0 dBic and axial ratio better than 2 dB. In effect the antenna is providing the performance one would expect of a much larger antenna. The antenna is not only mechanically robust but is less likely to be exposed to excessive damage by virtue of its reduced size.
| FEATURES | APPLICATIONS |
|---|---|
| Low profile | Warehouse |
| Extremely low VSWR and axial ratio | Distribution center |
| IP 67 Rated | Airports and hospitals |
| Weather and UV resistant radome | Transit terminals |
| Wide range of connector options | Conveyor belt |
| Left hand and right hand CP versions |
